1月3日佳能入魔爆料佳能EOS-1D X Mark III的完整规格

花冠摄影者

1月3日佳能入魔爆料佳能EOS-1D X Mark III的完整规格

Here are the full specifications for the Canon EOS-1D X Mark III
Canon Rumors
Jan 2, 2020 at 1:27 PM
Updated on Jan 3, 2020 at 3:29 AM
The formatting of these specifications is a bit messy, but you guys and gals are more than capable of figuring things out.

Our rumors were true, the Canon EOS-1D X Mark III remains at 20mp like it’s predecessor.

It looks like an official announcement is imminent.

Canon EOS-1D X Mark III Highlights:

20.1mp
16fps/20fps
ISO 100-102,400
4K at 60p (No DPAF in 4K)
Dual CFexpress card slots
Full Canon EOS-1D X Mark III Specifications:

Digital single-lens reflex AF / AE camera
Memory Card: Dual CFexpress
Image sensor size: 35.9 x 23.9 mm
Lens mount: Canon EF Lens Family
* Except for EF-S lens and EF-M lens (effective field of view is almost the same as the effective field of view of the lens focal length)
Image Sensor Type: CMOS
Image Sensors Resolution: 20 million pixels
* Rounded to 100,000 units
Aspect ratio: 3: 2
Dust removal function
Auto / Manual, Dust Delete Data Attached
Record format: DCF 2.0
Image format
JPEG (8bit), HEIF (10bit), RAW (14bit Canon original)
RAW + JPEG simultaneous recording is possible
RAW + HEIF simultaneous recording possible
* 12-bit A / D conversion processing is applied to RAW images taken with the electronic shutter
Record Pixels
JPEG
L Approx. 20 million pixels (5472 × 3648)
M1 Approx.12.7 million pixels (4368 × 2912)
M2 Approx.8.9 million pixels (3648 × 2432)
S approximately 5 million pixels (2736 × 1824)
HEIF L Approx. 20 million pixels (5472 × 3648)
RAW RAW / C-RAW Approx. 20 million pixels (5472 × 3648)
Storage function: Still photo / video split, Still photo save option, Movie save option, Still photo save / playback, Save / play video
Create and select folder possible
Filename: Default setting, user setting 1, user setting 2
File number: Continuous, auto reset, manual reset
Image processing during shooting
Picture style
Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Def. 1–3
White balance
Auto (Atmosphere Priority), Auto (White Priority), Preset (Sunlight, Shade, Cloudy, Tungsten, White, Fluorescent light, flash),
User setting, color temperature setting (approximately 2500-10000 K)
White balance correction and white balance bracketing
Flash color temperature information can be sent
White balance correction
Blue / amber correction: ± 9 levels
Magenta / Green Correction: ± 9 Levels
White Balance Bracketing
± 3 stops in 1-stop increments
Automatic Image Brightness Correction
Auto brightness optimization
Noise reduction
Applicable for high ISO speed shots and long exposures
Highlight tone priority
Lens aberration correction
Peripheral Illumination Correction, Distortion Correction, Digital Lens Optimization, Chromatic Aberration Correction, Diffraction Correction
Viewfinder: Eye Level Pentaprism
Field of view (range): Approximately 100% of width / length (eye point approximately 20mm)
Magnification: 0.76x (-1m–1 with 50 mm lens at infinity)
Diopter: 20 mm (at eyepiece end / -1 m-1)
Diopter adjustment range: -3.0 – +1.0 m-1 (dpt)
Depth-of-field previewsupport
Auto focus [Viewfinder Shooting]
Focus method:TTL secondary imaging phase difference detection method (using dedicated AF sensor)
AF point: Up to 191 points (cross-type AF point: up to 155 points)
Number of available AF points, number of dual cross-type AF points and cross type AF
The number of points depends on the lens used.
Dual cross-type focusing at F2.8 with center AF point
Focus brightness range: EV -4 – 21 (F2.8 compatible center AF point, One-Shot AF, Room temperature, ISO 100)
Focus action: One-Shot AF, AI Servo AF, Manual Focus (MF)
AF area selection mode: Manual selection: Spot AF, Manual selection: 1 point AF, AF area extension: Landscape / Portrait, AF area extension: Surround,
Manual selection: Zone AF, Manual selection: Large zone AF, Auto selection AF
Subject Recognition AF
EOS iTR AF settings (color information, face and head can be identified)
iTR: Intelligent Tracking and Recognition
AF configuration tool Case 1 – 4, Case A
AI Servo AF Characteristics
Tracking Sensitivity, Acceleration / Deceleration Tracking
AF fine adjustment
AF Microadjustment (All lenses by same amount, Adjust by lens)
AF assist light
Flash from external flash for EOS camera
[Live View Shooting / Movie Recording]
Focus method
Dual Pixel CMOS AF
* AF is not available when recording RAW or 4K 59.94 p / 50.00 p (NTSC / PAL) movies.
AF method: Face + Tracking, Spot AF, 1 Point AF, AF Area Expansion (Horizontal / Vertical), AF Area Expansion: Ambient, Zone AF,
Large Zone AF: Vertical, Large Zone AF: Horizontal
Available AF Frame Position Up to 3,869 locations
* When selected with multi-controller
AF areas available for auto selection
Up to 525 points
Eye detection AF support
Magnified view: 5 times / 10 times
AF area
Horizontal: Approx. 90%, Vertical: Approx. 100%
Horizontal: Approx. 80%, Vertical: Approx. 80%
* Depends on the lens used.
Manual focus (MF)
MF peaking, focus guide
[Live View Shooting]
AF operation
One-Shot AF, Servo AF, Continuous AF possible
Focus brightness range: EV -6 – 18
(F1.2, center AF point, room temperature, ISO 100, One-Shot AF)
AF configuration tool: Case 1–4, Case A
Servo AF Characteristics
Tracking Sensitivity, Acceleration / Deceleration Tracking
[Record video]
Focus brightness range: EV -4 – 18
(f/1.2, center AF point, room temperature, ISO 100, One-Shot AF, 29.97 fps)
Video Servo AF support
Video Servo AF Characteristics
Tracking Sensitivity, AF Speed
Exposure control
Metering mode
Viewfinder shooting: 216-division (18×12) TTL using approximately 400,000-pixel RGB + IR metering sensor
Open metering
Live View shooting / Movie recording: 384 split (24×16) metering using signals from the image sensor
Metering mode
Viewfinder shooting:
Evaluative metering
Partial metering (approximately 6.2% of screen)
Spot metering (approximately 1.5% of screen)
* AF point-linked spot metering and multi-spot metering options included.
Center-weighted average metering
Live View shooting: Evaluative metering, partial metering (approximately 5.8% of the screen), spot metering (approximately 2.9% of the screen)
Video recording: center-weighted average metering, evaluative metering
* Automatically set according to shooting conditions.
Focus brightness range
Viewfinder shooting: EV 0 – 20 (room temperature, ISO 100)
Live View shooting / Movie recording: EV -3 – 20 (at room temperature, ISO 100)
Shooting mode
Taking still photos:
Program AE, Shutter-Priority AE, Aperture-Priority AE, Manual Exposure, Bulb
Exposure, Custom Shooting Mode
(C1 / C2 / C3)
Video recording:
Program AE, Shutter-Priority AE, Aperture-Priority AE, Manual Exposure,
Custom Shooting Mode (C1 / C2 / C3)
ISO sensitivity (recommended exposure index)
Taking still photos:
ISO Auto (automatic setting in the range of ISO 100 – 102400),
Manual setting in ISO 100 – 102400 range (in 1 / 3- or 1-stop increments), L (equivalent to ISO 50),
Sensitivity extended to H1 (equivalent to ISO 204800), H2 (equivalent to ISO 409600), and H3 (equivalent to ISO 819200)
possible
* When highlight tone priority setting: ISO 200 – 102400
Video recording:
Program AE / Av / Tv: ISO Auto (automatically set within the range of ISO 100 – 25600), H1 (ISO 204800 equivalent)
M: ISO Auto (automatically set within the range of ISO 100 – 25600),
Manual setting in ISO 100 – 25600 (in 1 / 3- or 1-stop increments), H1 (ISO 204800
Sensitivity can be extended
* When highlight tone priority setting: ISO 200 – 25600
ISO sensitivity settings
Taking still photos:
SO speed setting range, auto range, minimum shutter speed
Video recording:
ISO sensitivity setting range, automatic maximum value
Exposure compensation
Manual: ± 5 stops in 1 / 3- or 1 / 2-stop increments (viewfinder shooting),
± 3 stops in 1 / 3- or 1 / 2-stop increments (Live View shooting, movie recording)
AEB: ± 3 stops in 1 / 3- or 1 / 2-stop increments (can be combined with manual exposure compensation)
AE lock
Still photo shooting:
Auto: AE lock with Custom Function when focus is achieved in each metering mode can be set on / off
Manual: using the AE lock button
Movie recording: using the AE lock button
Flicker Reduction
Available (when viewfinder shooting)
Multiple exposure
Function / operation priority, continuous shooting priority
Multiple exposures: 2 – 9 times
Multiple exposure control
Increase, average, brighten, darken
HDR shooting (still picture HDR PQ)
Record format
HEIF
Bit depth
10bit
Color sampling
YCbCr 4: 2: 2
HDR specification
ITU-R BT.2100 (PQ)
Electronically controlled focal plane shutter
Shutter method
Viewfinder shooting: mechanical
Live View shooting: mechanical, electronic curtain, electronic
Mechanical / electronic curtains: 1/8000 sec – 30 sec, bulb
Electronic setting: 1/8000 sec – 0.5 sec
Maximum shutter speed during flash synchronization: 1/250 sec.
* The setting range is different for movie recording.
Drive modes: Single shot, high speed continuous shooting, medium speed continuous shooting, low speed continuous shooting, one soft shooting, soft continuous shooting
Shooting, soft low-speed continuous, self-timer: 10 seconds, self-timer: 2 seconds
Continuous shooting speed: One-Shot AF up to approx. 16 shots / sec
(Setting range: 3-16 sheets / sec)
Up to approx. 20 shots / sec
AI Servo AF / Servo AF
Medium speed continuous shooting: One-Shot AF Approx. 10 shots / sec
(Setting range: 2-15 sheets / sec)
Approx. 10 shots / sec. * 3
AI Servo AF / Servo AF
Time lapse
One-Shot AF Approx.3.0 shots / sec
(Setting range: 1-14 sheets / second)
Approx.3.0 sheets / sec
AI Servo AF / Servo AF
Soft continuous shooting
8.0 shots / sec
(Setting range: 2-8 sheets / second)
Approx. 10 shots / sec. * 3
Need for Speed
The Canon EOS-1D X Mark III will be blisteringly fast – offering exceptional precision, reliability, high-performance autofocus, and subject tracking – providing photographers with a tool that will help to capture the shot they are chasing. The camera’s new autofocus algorithm will improve stability and tracking when using both the Optical Viewfinder and in Live View shooting mode, using Deep Learning Technology and adapting to help facilitate accurate focus tracking for every shot. When using the optical viewfinder the camera will use a new autofocus sensor, with approximately 28 times the resolution in the center of the EOS-1D X Mark II. Offering the ability to autofocus in even brighter and darker situations than before and with greater precision, the camera will have a range of autofocus capabilities, which will enable the photographer to get their shot. In Live View mode, users will be able to make use of 525 AF areas using the Dual Pixel CMOS AF system will cover approximately 90×100 percent of the image sensor. The camera will support significantly faster frame rates with full AF and AE, using either the optical viewfinder (up to approximately 16 fps mechanical shutter) or Live View (up to approximately 20 fps mechanical or electronic shutter). Additionally, the camera’s dual CFexpress card slots will enable more than five times the RAW burst depth of its predecessor.

Powered to Dominate
The development of EOS-1D X Mark III is a clear example of Canon’s commitment to pushing the boundaries of innovative imaging products featuring optically excellent technology. The camera will support an all-new, Canon-developed, CMOS sensor and DIGIC processor, that will deliver greater image quality, at even higher ISOs, with the ability to capture stills in 10-bit using the HEIF (High-Efficiency Image File) file format. HEIF produces wider dynamic range and greater color representation compared to JPEG. The power of 4K resolution brings stories to life – shoot 4K videos including 4K60p with 10-bit 42 Canon Log internal recording.

Conveniently Connected
For professionals, content delivery is just as important as image capture – the EOS-1D X Mark III will make it easy, featuring built-in Wi-Fi and Bluetooth low-energy connectivity in addition to GPS technology. To keep pace with ever-shortening deadlines, the camera will transfer data at more than twice the speed of the EOS-1D X Mark II when using the built-in Ethernet connection, or the new optional wireless file transmitter – the WFT-E9, which is also compatible with Canon’s recently launched Cinema EOS C500 Mark II camera. Coupled with simpler network set-up the camera will greatly enhance the professional workflow

A Familiar Feel with Improved Attributes
Existing EOS-1D series users will be familiar and comfortable handling the EOS-1D X Mark III allowing seamless navigation with trusted ergonomics – whilst the magnesium alloy body will offer the durability expected from Canon’s EOS-1D cameras. Professional photographers can trust the same impressive build-quality as the EOS-1D X Mark II – with phenomenal weather-sealing, standing up to harsh conditions, including wind, rain, and humidity. With incredible low-light shooting capabilities, the camera will now feature select illuminated buttons that allow for precision operation in challenging, dark and dimly lit conditions. The camera will also offer a new additional control for selecting AF points, built into the AF-ON button, allowing photographers to change AF points on-the-fly for the best composition – further helping to simplify their work. In addition, dramatically improved battery life – with the same LP-E19 – will allow professionals to shoot for longer periods of time, without having to change batteries, helping reduce the chance of missing a shot.

A new era in autofocus speed and accuracy
The EOS-1D X Mark III will feature a brand-new AF sensor with 28x more resolution than its predecessor, using advanced AF algorithms with deep learning technology for incredible focus tracking in any situation. And in Live View and video, there will be the added advantage of Dual Pixel CMOS AF across approximately 90×100 percent of the sensor with 525 AF areas. With AF over a wider EV range focusing with an EOS DSLR truly will never have been more accurate and versatile.

Outstanding stills and video
With a new Canon CMOS sensor and powerful new DIGIC processing, image quality even at high ISO will be taken to even greater levels along with 4K video at 60p, plus the options of capturing RAW video or 10-bit 42 video with Canon Log, both recorded internally to CFexpress cards. A new bright viewfinder will help connect you to your subject in real time.

High-speed camera communications
Delivering captured content quickly is the vital next step for a professional. This is why the EOS-1D X Mark III will feature Wi-Fi and Bluetooth low energy connectivity and GPS capability for seamless communication. With double the transfer speeds of the EOS-1D X Mark II, via the built-in Ethernet port or through the optional WFT-E9, and with a revised user interface for simpler and more intuitive operation, the new EOS-1D X Mark III will be designed to get the job done faster than any EOS ever before.

Always ready to perform, whatever the situation
The EOS-1D X Mark III will be radically upgraded for superb performance. Not only will it offer a blistering frame rate with the optical viewfinder including AE and focus tracking, but also dramatic improvements in Live View mode with the same level of accuracy, plus the ability to shoot using an electronic shutter. The camera will be engineered to excel in all areas, with dramatically improved battery life using the LP-E19 battery, new illuminating buttons and an all-new AF point selection control within the AF-ON button in addition to the multi-controller. All in a magnesium alloy weather-sealed body.

Canon 1DX Mark III Features:

A new era in autofocus speed and accuracy
Outstanding stills and video
High-speed camera communications
Always ready to perform, whatever the situation
Enhanced DIGIC Processor
New CMOS Sensor
16 fps Mechanical Shutter, with Optical Viewfinder
20 fps Mechanical or Electronic Shutter, During Live View
Backlit buttons
Canon 1D X Mark III specs:

Lens Mount        Canon EF
Camera Format        Full-Frame (1x Crop Factor)
Pixels        Not Specified by Manufacturer
Sensor Type        CMOS
Image File Formats        JPEG, HEIF, Raw
Bit Depth        8, 10, 14-Bit
Continuous Shooting        16 fps (Mechanical Shutter, with Optical Viewfinder)
20 fps (Mechanical or Electronic Shutter, During Live View)
Focus Type        Auto and Manual Focus
Autofocus Points        Phase-Detection: 525 (During Live View Only)
Viewfinder Type        Optical (Pentaprism)
Video Recording        42 10-Bit
4K at 59.94p fps
Memory Card Slot        Dual Slot: CFexpress
Wireless        Bluetooth
Wi-Fi
GPS        Yes
Battery        1 x LP-E19 Rechargeable Lithium-Ion, 11.1 VDC, 2750 mAh

阿帕奇

能翻译一下吗？

黄河老蔡

下周正式发布！

sdgd5135

牙膏挤不出来了！

花冠摄影者

阿帕奇 发表于 2020-1-3 21:04
能翻译一下吗？

你可以使用网络在线自动翻译，

大家多数人是这样看的。

阿帕奇

花冠摄影者 发表于 2020-1-4 09:40
你可以使用网络在线自动翻译，

大家多数人是这样看的。

好的，谢谢
